Applications & Markets
- Design provides reliable performance and no spillage during maintenance or service
- Standard seal material: EPDM, additional material available on request
Physical Characteristics
Hansen FD83 Electronics Cooling Couplings by Danfoss Hansen is the perfect solution for fluid transfer and electronics cooling applications. With its interlocking features, it provides maximum safety by preventing spills and ensuring that valves cannot be opened until the coupling halves are mated. The coupling also offers full flow and fluid compatibility, making it a reliable choice for any project. Plus, the coupling halves cannot be disconnected until both halves are closed, providing added security and peace of mind. Used in Data Centers, Mobile Battery Cooling, and Thermal Management Systems
Maximum Operating Pressure
- Standard body material: 303 stainless steel
- Full flow coupling
- Color coded bumper seals are available
Figure 2
- Data Centers
- Mobile Battery Cooling
- Thermal Management Systems
- Industrial Fluid Transfer
Figure 1
| Dimensions | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | Body Size | Port Size | Thread | Type | Fig. | A | B | Hex | |||
| mm | (in) | mm | (in) | mm | In | ||||||
| FD83-2052-16-16 | 1 | 1 | 1-11-1/2 | Female NPTF | 1 | 95.5 | 3.76 | 71.6 | 2.82 | 41 | 1.63 |
| FD83-2052-12-16 | 1 | 3/4 | 3/4-14 | Female NPTF | 1 | 70.1 | 2.76 | 71.6 | 2.82 | 41 | 1.63 |
| FD83-2046-16-16 | 1 | 1 | N/A | 1" Hose Barb | 2 | 84.2 | 3.31 | 71.6 | 2.82 | - | - |
| FD83-2092-16-16 | 1 | 1 | N/A | 1" Hose Barb 90° | 3 | 125 | 4.92 | 71.6 | 2.82 | - | - |
| FD83-2096-16-16 | 1 | 1 | 1 5/16-12 | Male ORB | 5 | 95.5 | 3.76 | 71.6 | 2.82 | 41 | 1.63 |
| FD83-2140-16-16 | 1 | 1 | G1-11 | Male BSPP | 5 | 95.5 | 3.76 | 71.6 | 2.82 | 41 | 1.63 |
| FD83-2126-16-16 | 1 | 1 | G1-11 | Female BSPP | 1 | 84.3 | 3.32 | 71.6 | 2.82 | 41 | 1.63 |
| FD83-2128-16-16 | 1 | 1 | N/A | Sanitary Flange 1" | 4 | 79.6 | 3.13 | 71.6 | 2.82 | - | - |
| FD83-2126-32-32 | 2 | 2 | G2-11 | Female BSPP | 1 | 122.4 | 4.82 | 105.3 | 4.15 | 70 | 2.76 |
| FD83-2127-32-32 | 2 | 2 | N/A | 2" Hose Barb | 2 | 166.9 | 6.57 | 105.3 | 4.15 | - | - |
| FD83-2128-32-32 | 2 | 2 | N/A | Sanitary Flange | 4 | 102.4 | 4.03 | 105.3 | 4.15 | - | - |
| FD83-2052-32-32 | 2 | 2 | 2-11-1/2 | Female NPT | 1 | 122.4 | 4.82 | 105.3 | 4.15 | 70 | 2.76 |
Danfoss Hansen´s FD83 coupling is designed for fluid transfer and electronics cooling applications where full flow, fluid compatibility and safety are essential. Used in Data Centers, Mobile Battery cooling, Thermal Management Systems, and Industrial Fluid Transfer
- Identical coupling halves
- Maintenance and service friendly
- 303 stainless steel material provides broad fluid compatibility
- Wide range of terminal end options
- Dual interlock safety feature eliminates accidental opening of coupling when disconnected with the use of a patented locking pin design and lever handle
Figure 3
Minimum Burst Pressure
| Coupling Size | Connected | Socket/Female Half | Socket/Female Half | Connected | Socket/Female Half | Socket/Female Half | Rated flow | Fluid Loss | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (bar) | (psi) | (bar) | (psi) | (bar) | (psi) | (bar) | (psi) | (bar) | (psi) | (bar) | (psi) | (lpm) | (gpm) | cc. max |
| 1 | 10 | 150 | 10 | 150 | 10 | 150 | 20 | 300 | 20 | 300 | 20 | 300 | 189 | 50 | 5.0 |
| 2 | 10 | 150 | 10 | 150 | 10 | 150 | 20 | 300 | 20 | 300 | 20 | 300 | 800 | 211 | 12 |
